Slaughter House Overhead Conveyor – Technical Specifications

• Structure:

  • Material: Stainless Steel (SS) for corrosion resistance

  • Finish: Food-grade finish, resistant to moisture and cleaning agents

  • Design: Open or closed track with smooth surfaces to prevent contamination

• Track Type:

  • Precision-formed steel or stainless steel track

  • Modular or continuous track design for smooth operation

  • Curve radius: Minimum 450 mm for efficient navigation

• Trolley Design:

  • Wheels: Stainless steel or plastic wheels with ball bearings

  • Material: Corrosion-resistant alloys or food-grade plastic

  • Load Capacity: 200–500 kg per trolley, depending on system size

  • Spacing: Adjustable, typically 12” or 24” centers

• Drive Unit:

  • Motor: 1 to 5 HP, with explosion-proof or washdown duty motors

  • Speed: 3 to 15 m/min, adjustable via VFD (Variable Frequency Drive)

  • Type: Chain-driven or friction drive, depending on load

• Chain:

  • Material: Stainless steel or plastic-coated chain for hygienic transport

  • Pitch: Typically 6” or 8”

  • Breaking Load: 2,000–5,000 kg depending on system design

• Special Features:

  • Sanitation: Easy-to-clean design to meet hygiene standards

  • Incline/Decline: Capable of handling up to 30° inclines/declines for efficient transport

  • Temperature Resistance: Designed to handle temperatures from freezing to hot environments

• Applications:

  • Transporting carcasses, offal, and meat products in slaughterhouses

  • Suitable for automated or semi-automated processing lines

  • Compatible with food-grade certifications
